Item # MGP1036A, Everlast 10.25" Dia 36-Tooth 5/8" Bore 0.070" Plate 0.095" Kerf General Purpose Cut-Off Saw - Alternate Top Bevel
Download as PDF
Thank you for shopping with us.
Designed for all around general purpose cutting in solid woods, plywood, masonite, chip core, and laminated formica (single-sided).
Alternate Top Bevel - ATB - Each tooth has top bevel typically between 10 and 20 degrees. Two teeth are required to provide a full kerf cut. Provides low cutting pressures, which reduce material tearing during the cutting process and provides a fine cutting finish. Best performance cross cutting.
MG1024A- Bore has diamond knock-out. Designed for use with hand-held saws such as Big Foot Brand.
Designed for all around general purpose cutting in solid woods, plywood, masonite, chip core, and laminated formica (single-sided).
Alternate Top Bevel - ATB - Each tooth has top bevel typically between 10 and 20 degrees. Two teeth are required to provide a full kerf cut. Provides low cutting pressures, which reduce material tearing during the cutting process and provides a fine cutting finish. Best performance cross cutting.
MG1024A- Bore has diamond knock-out. Designed for use with hand-held saws such as Big Foot Brand.
| SPECIFICATIONS | |
| Manufacturer | Everlast |
|---|---|
| Diameter | 10.25 in |
| Bore | 5/8 in |
| Grind | ATB |
| Kerf | 0.095 in (2.4 mm) |
| Plate | .070 in (1.8 mm) |
| Teeth | 36 |
| Hook Angle | 10 deg |
| Note | Bore has diamond knock-out. Designed for use with handheld saws such as Big Foot brand. |
