Item # TCTCT1640A, Everlast Truss & Component Saw - 16" Dia 40-Tooth 2.5" Bore 0.134" Plate 0.185" Kerf
$285.11
Download as PDF
Thank you for shopping with us!
These saws are the workhorses of truss plants and are designed to provide a long service life and excellent cutting performance. Countersunk (80°) holes will accept 5/16" flat head bolt.
Alternate Top Bevel - ATB - Each tooth has top bevel typically between 10 and 20 degrees. Two teeth are required to provide a full kerf cut. Provides low cutting pressures, which reduce material tearing during the cutting process and provides a fine cutting finish. Best performance cross cutting.
These saws are the workhorses of truss plants and are designed to provide a long service life and excellent cutting performance. Countersunk (80°) holes will accept 5/16" flat head bolt.
Alternate Top Bevel - ATB - Each tooth has top bevel typically between 10 and 20 degrees. Two teeth are required to provide a full kerf cut. Provides low cutting pressures, which reduce material tearing during the cutting process and provides a fine cutting finish. Best performance cross cutting.
| SPECIFICATIONS | |
| Manufacturer | Everlast |
|---|---|
| Bore | 2.5 in |
| Diameter | 16 in |
| Countersink | 4/.40"; 6.0" Bolt Hole Circle Dia |
| Kerf | 0.185 in - 4.7 mm |
| Machine | XL-Saw |
| Grind | ATB |
| Plate | 0.134 in - 3.4 mm |
| Teeth | 40 |
| Hole Size | 6/64mm Bolt Hole Circle Dia |
