Item # S524, Everlast Astra Series 5" /125mm Dia 24-Tooth 5/8" Bore 8° Hook Scoring Saw- Straight Top & Conical Sides
$139.04
Download as PDF
Thank you for shopping with us!
Used on both sliding carriage and beam type panel saws to score the bottom of panels, thus allowing a large saw to cut through without chipping material on bottom side.
Straight Top Grind - STR - Each tooth will cut full kerf making this design very effective for removing material however high cutting pressures are present. Typically used for rip cutting hardwood and softwood.
Used on both sliding carriage and beam type panel saws to score the bottom of panels, thus allowing a large saw to cut through without chipping material on bottom side.
Straight Top Grind - STR - Each tooth will cut full kerf making this design very effective for removing material however high cutting pressures are present. Typically used for rip cutting hardwood and softwood.
| SPECIFICATIONS | |
| Diameter | 5 in125 mm |
|---|---|
| Bore | 5/8 in |
| Grind | STR (conic) |
| Kerf | Kerf ground to match panel saw |
| Pinholes | As required |
| Plate | Plate thickness to match panel saw |
| Teeth | 24 |
| Manufacturer | Everlast |
