Item # LU96R010, Freud Thin Kerf Double-Sided Laminate/Melamine Blade: LU96R Series

$86.74

Download as PDF

Edge of Arlington offers free shipping in the United States when you choose flat rate shipping.

Application: For Ultra Long Life in Double-Sided Man-made Materials

The LU96R is a thin kerf blade that is designed to give long life and excellent finish on the top and bottom of laminates, melamine, and veneered plywood. The laser-cut anti-vibration design yields the plate acoustically dead. This reduces the sideways movement of the cutting edge to prevent chipping in man-made materials such as laminates. This dramatically extends cutting life and finish. No scoring blades needed with this blade!

Premium TiCo™ HI-Density Carbide Laminate Blend for Maximum Performance. Triple Chip Grind (TCG) Tooth Design with a positive hook angle for long life in production applications. Thin Kerf requires less power and allows for faster feed rate. Perma-Shield® Non-Stick Coating reduces blade drag, protects the blade from corrosion and pitch buildup.

Ideal For: Double-sided laminates, melamine & veneered plywood. Depth of cut (1/4" min to 1-5/8" max).

Tip: Proper blade height is essential to chip-free cuts. If you experience chipping on the bottom of the material, lower the blade slightly. If there is chipping on the top of the material, the blade height should be increased slightly.




SPECIFICATIONS
Diameter10 in
Arbor5/8 in
Kerf.091 in
Plate.071 in
Teeth80 TCG
TypePerma-SHIELD™
ManufacturerFreud Tools
