Item # LU5C01, Freud®180mm Dia, 20mm Arbor, TCG, -6 deg Hook Angle, 42 Tooth Saw Blade to Cut Non-Ferrous Metals: Series LU5C
Original price was: $62.02.$55.82Current price is: $55.82.
Download as PDF
Thank you for shopping with us! Carbide-Tipped blade for cutting aluminum and non-ferrous metals with Freud's exclusive TiCo Hi-Density Carbide designed and manufactured specifically for each cutting application to maximize cutting life.
Silver I.C.E. Coating prevents build-up on the blade surface and keeps the blade running cooler and cleaner.
Machines: Miter saws with manual or mechanical clamping of the piece
Features: Flat-triple chip tooth with positive cutting angle
Material: Aluminum and non-ferrous metals
Ideal For: To cut drawn products and tubes where the thickness exceeds 3mm. It is recommended to use it with the sawblade over the workpiece to be cut.
Silver I.C.E. Coating prevents build-up on the blade surface and keeps the blade running cooler and cleaner.
Machines: Miter saws with manual or mechanical clamping of the piece
Features: Flat-triple chip tooth with positive cutting angle
Material: Aluminum and non-ferrous metals
Ideal For: To cut drawn products and tubes where the thickness exceeds 3mm. It is recommended to use it with the sawblade over the workpiece to be cut.
| SPECIFICATIONS | |
| Manufacturer | Freud Tools |
|---|---|
| Diameter | 180 mm |
| Arbor | 20 mm |
| Hook Angle | -6 deg |
| Kerf | 2.8 mm |
| Pinholes | -- |
| Plate | 2.2 mm |
| Teeth | 42 |
| Type | Silver Ice |
| Grind | TCG |
