Item # 49346, Amana Tool Binding/Rabbeting 20mm (51/64) Dia x 13.5mm (17/32) x 1/4 Inch Shank Router Bit Set
$65.26
Download as PDF
Thank you for shopping with us!
Carbide-Tipped – Down shear angle – 3 Flute with ball bearing guide.
Special set designed for Luthier. This set includes five different bearings that will give five rabbet sizes (Ledge cut).
Included Ball Bearings
1mm (3/64) Rabbet 47664
1.5mm (1/16) Rabbet 47663
2mm (5/64) Rabbet 47662
2.5mm (3/32) Rabbet 47661
3mm (1/8) Rabbet 47660
Carbide-Tipped – Down shear angle – 3 Flute with ball bearing guide.
Special set designed for Luthier. This set includes five different bearings that will give five rabbet sizes (Ledge cut).
Included Ball Bearings
1mm (3/64) Rabbet 47664
1.5mm (1/16) Rabbet 47663
2mm (5/64) Rabbet 47662
2.5mm (3/32) Rabbet 47661
3mm (1/8) Rabbet 47660
| SPECIFICATIONS | |
| Manufacturer | Amana Tool |
|---|---|
| Cut Depth | 9/64, 5/32, 11/64, 13/64, 7/32 in |
| Diameter | 51/64 in (20mm) |
| Bearing(s) | 47660, 47661, 47662, 47663, 47664 |
| Cut Height, Length, or Width | 17/32 in (13.5mm) |
| Overall Length | 2 1/8 in |
| Shank | 1/4 in |
| Flute | 3 w/BB guide |
